SUX65-12(CVF) Solid insulated ring cabinet

GMX65-12 (CVF) solid insulated ring network cabinet switchgear is a new generation of environmentally friendly solid insulated ring network cabinet developed by the company. It is mainly composed of three functional units, namely V unit (breaker unit), C unit (load switch), F unit (combined electric unit), each unit can be used alone or freely, and its structure is divided into intelligent control instruments. The chamber, the operating mechanism and the primary part, the instrument room can be equipped with a microcomputer protection (controller), the mechanism is a special elastic operation mechanism, and the APG automatic gel process is used in one part, and the isolation switch and the arc extinguishing chamber are completely sealed in the epoxy resin. There are special connectors and busbars connected. The design switch of the arc extinguishing chamber uses the special copper-chromium contact material, the R-type vertical magnetic field contact, and the complete primary sealing process. The arc-breaking chamber breaks the short-circuit current capability, stability, electrical life and temperature. The rise and insulation levels are significantly improved compared to the previous arc-extinguishing chamber (copper-aluminum contact material, cup-shaped longitudinal magnetic field contact structure, and incomplete primary sealing process). The operating mechanism adopts a sliding mechanism integrated with the switch, that is, the isolating switch and the main switch playing mechanism are integrated, which can easily realize interlocking, and has fewer mechanism parts, reduces unnecessary transmission links, and has high reliability, and Electric operation can be added according to user needs.
