HXGN15-12 Unit AC metal closed ring switchgear

HXGN15-12 unit type AC metal-enclosed ring network switchgear (hereinafter referred to as ring network cabinet) is a new generation of high-voltage electrical products designed and developed by us in the introduction of foreign advanced technology and in accordance with the requirements of domestic agricultural power and urban network transformation. The technical performance indicators are all IEC62271-200:2003 and GB3906 standards. The main switch, operating mechanism and components of the ring network cabinet adopt the original ABB original parts or the SFL-12/24 type switchgear which is assembled and produced domestically with imported components. It can also be equipped with ABB original HAD/US type SF6 according to user needs. Circuit breaker or VD4-S vacuum circuit breaker. Its operation mode is divided into manual and electric. The cabinet is riveted by CNC machine tool, the protection level is IP3X, and it has reliable mechanical interlock and anti-misoperation function. This product has the characteristics of small size, light weight, beautiful appearance, easy operation, long life, high parameters, no pollution, and less maintenance. HXGN15-12 unit type AC metal-enclosed ring network switchgear, suitable for AC 50Hz, 12kV power network, as the acceptance and distribution of electric energy. The main switch in the cabinet is the SF6 switch.
